JBL | Concert A652 – 170 Watts 2 Channel Amplifier For Speakers Or Subwoofer

• Powerful Class AB amplifier – Class AB amplifier output stage combines the advantages of the Class A amplifier and the Class B amplifier while minimizing the problems of low efficiency and distortion associated with them.
• Adjustable High-Pass/Low-Pass Crossover Filter – Concert amplifiers have the High-Pass Filter (HPF) and the Low-Pass Filter (LPF), which allow you to adjust the frequency from 40Hz to 400Hz based on your own music taste to deliver the appropriate musical frequencies to speakers.
• Auto Turn On Facility – When using the High-level signal inputs, the amplifier automatically turns on once a DC offset is detected (>2.5 volts). When using the Line-level signal inputs, the amplifier will also turn on once a +12V signal is detected from the remote turn-on wire.

• Efficient Cooling Design – High performance amplifiers are not only powerful but also compact which depend on overall Efficient Cooling Design.

• Concert Sound and Elegant Looks – JBL Concert amplifiers deliver extraordinary sound experience with elegant industry design.

• Reliable Performance – In order to deliver high quality sound and reliable performance, the high-quality component such as audio capacitors, power MOSFET are selected for Concert amplifiers. Those amplifiers also have to undergo a rigid testing process that would destroy unstable amplifiers. JBL freezes them, bakes them, shakes them, blasts them with ultraviolet light and drives them at full power for days at a time.



SPECIFICATIONS:

• 2-Channel Class AB Car Amplifier
• Rated Power RMS Output:
• 65W x 2 @ 4 ohm; 85W x 2 @ 2 ohm; 170W x 1@ 4 ohm bridged, <1%THD
• Full/High-pass/Low-pass Filter:
• 40-400Hz,12dB/octave
• SN Ratio (1W @ 4 ohms): >75dB
• Frequency Response (-3dB): 10Hz – 45kHz
• Gross weight: 2.15kg
